COMP Cams Camshaft CRS 268Ah-10 - cca20-309-4

*Magnum Camshafts* * Great high RPM power * Easy on valve train parts * Can be used with mild ratio rocker arms and traditional performance valve springsAvailable * Best with aftermarket converter and 9.5:1+ compression PartNumber : cca20-309-4 Description : Magnum Muscle Camshaft Title : 20-309-4 CamShaft, CRS 268AH-10 Valve Springs Required : Yes Advertised Exhaust Duration : 276 Advertised Intake Duration : 268 Assembly Lubricant Included : Yes Basic Operating RPM Range : 1,800-5,800 California Proposition 65 : WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov Cam Type : Hydraulic Flat Tappet Camshaft Gear Attachment : 1-Bolt Camshaft Material : Cast Iron Camshaft Series : Magnum Muscle Engine Family : Chrysler 273-360 c.i. 8 Cylinder (1964-2002) Exhaust Duration at .050 inch Lift : 226 Exhaust Valve Lift : 0.464 Grind Number : 268AH-10 Intake Duration at .050 Inch Lift : 222 Intake Valve Lift : 0.464 Lifter Style : Hydraulic Flat Tappet Lifters Included : No Lobe Separation : 110 Usage : Street/Performance Cam and Lifter Kit Upgrade : CL20-309-4 Exhaust Duration @ .050 in. : 226 Lifter Type : Hydraulic Flat Tappet Intake Duration @ .050 in. : 222 Intake Duration : 268 Intake Valve Lift(in) : 0.464 Exhaust Duration : 276 RPM Range : 1000-7000 Exhaust Valve Lift(in) : 0.464 Engine Components::Camshafts
